A High Efficiency Power Amplifier Integrated with a CPW Patch Antenna

Name: A High Efficiency Power Amplifier Integrated with a CPW Patch Antenna
Brand: VDM Verlag Dr. Müller
SKU: 9783639208450
Price: 20655 HUF
Availability: InStock

A First Design Iteration

Szerző: Jean-Paul L. Prévost

Nyelv:

Kötés: Puha kötésű

Kiadó: VDM Verlag Dr. Müller

Elérhetőség: Kiadói készleten rendelésre

Küldés 17-27 napon belül

20 655 Ft

In this work, the CPW-fed aperture-coupled patch antenna is studied for the purpose of integration w...

Információk a könyvről

Szerző

Jean-Paul L. Prévost

Nyelv

Angol

Kötés

Könyv - Puha kötésű

Kiadva

2009

oldal

124

EAN

9783639208450

Enbook ID

06828798

Kiadó

VDM Verlag Dr. Müller

Súly

201

Méretek

150 x 220 x 7

Teljes leírás

In this work, the CPW-fed aperture-coupled patch antenna is studied for the purpose of integration with a high efficiency power amplifier. The design of a high-efficiency power amplifier using an active multi-harmonic load-pull system is described. The load-pull system is constructed using six-port circuits and can independently vary the output load of a transistor at its fundamental operating frequency, as well as at the second and third harmonics. The system is used to find the efficiency-optimizing output loads of a commercial transistor operating at a class B bias point. A power amplifier with a gain of 7.1 dB and a PAE of 58.6% operating at a fundamental frequency of 3.5 GHz with an input power of 4mW is obtained. A CPW-fed slot-coupled patch antenna is designed to act as both a radiating element and an impedance element, producing the transistor s experimentally determined efficiency-optimizing load at the fundamental frequency. A CPW circuit comprising of internally patterned series stubs is added to the input of the antenna in order to produce the transistor's optimal loads at the second- and third-harmonic frequencies.
